Asset Purple Textured

sweetpeatexturizedsmall

TEXTURE !



Yesterday I shared my recent Affinity Designer vector drawings to be assets,  which I can reuse, resize, and recolor.  An asset maintains all the layers and effects, so any and all can be changed.

Today, I followed the tutorial by Frankentoon’s blog post to texturize my original and FLAT sweet pea design.

 Texture

I needed some texture so I finally opened one of my photos I deliberately took as a possible texture: the ripples in a sand dune.

duneripples

I opened it in Affinity Photo and actually tried a bunch of things, but the main thing to do is to increase the contrast, so the photo becomes mostly black and mostly white— high contrast. I got this:

blackwhiteripples



That’s what I placed in my document. I copied it and “clipped” it to each object element of my sweet pea flower.  I set the layer to blend mode “multiply.” Each petal, sepal, stem are separate objects and each needed a texture. I enlarged or decreased the size, turned it around, and found the exact form of texture that fit each of those objects.

GRADIENT

Next, to each element I added appropriately colored and distributed gradients.  So, some areas of an element needed to be lighter and others darker, and each of those can be adjusted with the gradient tool.

SHADOW

To create shadows, clip a new pixel layer to the object. Go to “Pixel Persona” and choose your pixel brush and the paint brush tool.  I used  the Grunge 4 brush.  It looks like flower veins!  Wherever a darker shadow would be, I would paint it in. I set the blend mode of this layer to “multiply.”

HIGHLIGHT

Of course, the light is shining from somewhere — here it is from top left.  So I added highlights as well with same brush by clipping another new pixel layer to each object needing a highlight. Depending on the amount of highlight, I applied different blend modes to each of these layers: lighten, or screen, color dodge.

SWEETPEATEXTURIZEGRAPHIC

LAYERS

In my layers, you will see:

  • named groups [petals lower]
  • objects to create the group [lower top and lower low]
  • clipped photo for texture
  • clipped shadow [pixel layer]
  • clipped highlight [pixel layer]

The gradient fill doesn’t show as a separate element in the layers.

layerssweetpea

So.

BEFORE AND AFTER

before_after_texture_sweetpea

What do you think?

I think I’m learning!  Keep trying. Keep experimenting. Play. Share.
